Chapter 11. Dial Plan
61200305L1-1
ATLAS 550 User Manual
11-21
FGD T
X
S
EQUENCE
Write security: 3; Read security: 5
Defines to the ATLAS 550 the format in which to present the outgoing dig-
its. Choices:
N
ORMAL
if no digits are to be sent;
ANI/DNIS
to send both ANI
and DNIS;
DNIS
to send DNIS only;
ANI
to send ANI only.
FGD R
X
S
EQUENCE
Write security: 3; Read security: 5
Defines to the ATLAS 550, the format in which to receive the incoming dig-
its. Choices:
N
ORMAL
if no digits are to be received;
ANI/DNIS
to receive
both ANI and DNIS;
DNIS
to receive DNIS only;
ANI
to receive ANI only.
W
INK AFTER
ANI/
DNIS
Write security: 3; Read security: 5
When enabled, the ATLAS 550 will transmit a wink after ANI/DNIS digits
are transmitted.
D
IRECT
I
NWARD
D
IALING
Write security: 3; Read security: 5
Defines to the ATLAS 550 whether Direct Inward Dialing (DID) is used by
the user equipment. If
DID
is
E
NABLED
, then the following information must
be defined:
DID D
IGTS
T
RANSFERRED
Write security: 3; Read security: 5
Defines the number of digits the ATLAS 550 sends on to the user equip-
ment. This field only displays if
DID
is set to
E
NABLED
.
C
ALLER
ID N
UMBER
Defines the number the ATLAS 550 uses to provide caller ID to the network
for outgoing calls sent through this endpoint. This option only displays if
DID
is set to
D
ISABLED
. This item is optional.
S
TRIP
MSD
Write security: 3; Read security: 5
Strips a selected quantity (choose from
N
ONE
,
1
,
2
, and
3
) of the Most Signif-
icant Digits (MSD) of a dialed number prior to being forwarded out of the
port.
Example:
A network port could be set to accept all calls beginning with 9 (9$), and
then with
S
TRIP
MSD
set to
1
, all digits would be sent toward the network
except the leading 9.
If Feature Group D is used, DID refers only to DNIS digits.
The Caller ID number must be specific (i.e., no “wild cards”).
