Chapter 10. Dedicated Maps
61200305L1-1 ATLAS 550 User Manual 10-5
DS0 S A VAILABLE
Read security: 5
Indicates which DS0s of the T1 are assigned. DS0 assignment is based on
the following items:
T1 T ROUBLE C ODE S ERVICE
Write security: 3; Read security: 5
Sets known values in the data field for outgoing DS0s which are cross-con-
nected to a T1 port experiencing alarms. Choose from
O FF , V OICE , D ATA ,
and C USTOM , depending on the type of traffic on the T1.
T1 T RUNK C ONDITIONING S ERVICE
Write security: 3; Read security: 5
Sets known values in the signaling bits and the data field for outgoing DS0s
which are cross-connected to a T1 port experiencing alarms. The trunk con-
ditioning process consists of a 2.5-second transmission (indicating call ter-
mination), followed by a continuous transmission signaling the final
condition as chosen by the user. See the trunk conditioning example on
page 10-7.
Choose from O FF , V OICE E&M , V OICE LS/GS U SER T ERMINATION , V OICE LS/
GS N ETWORK T ERMINATION , D ATA SW56 , and C USTOM —depending on the
type of traffic or configuration of the T1.
0 - 9 This DS0 is available. The digit that displays in this field represents
the last digit of the DS0 number.
* This port is requesting this DS0 for this connection, but the DS0 is
not yet activated.
! This DS0 is used by this port in this connection and is activated.
S This DS0 is used in the switched Dial Plan.
S This DS0 is used in the switched Dial Plan and conflicts with this
connection.
N This DS0 is already used in this dedicated map.
N This DS0 is already used in this dedicated map and conflicts with
this connection.
T1 Trouble Code Service only applies to non-RBS T1s in the
D EDICATED M AP .
Trunk conditioning only applies to RBS T1s in the dedicated map.
