Chapter 31: 802.1x Port-based Network Access Control
734 Section VII: Port Security
Setting Port Roles
This procedure sets port roles. For an explanation of port roles, refer to
“Port Roles” on page 722. You must set up the port roles before you
enable port access control.
To set port roles, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 87 on page 291.
2. From the Security Configuration menu, type 1 to select Port Access
Control (802.1X).
The Port Access Control (802.1X) menu is shown in Figure 256.
Figure 256. Port Access Control (802.1X) Menu
3. From the Port Access Control menu, type 3 to select Configure Port
Access Role.
The following prompt is displayed:
Enter port list ->
4. Enter the port whose role you want to change. You can specify one
port or a range of ports (for example, 4-8), but not nonconsecutive
ports (for example, 4,6,11).
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Access Control (802.1X)
1 - Port Access Control .............. Enabled
2 - Authentication Method ............ RADIUS EAP
3 - Configure Port Access Role
4 - Configure Authenticator
5 - Configure Supplicant
6 - Display Port Access Status
7 - Configure Accounting
R - Return to Previous Menu
Enter your selection?
