Displaying ACLs
To display the ACLs on a switch, perform this procedure:
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 87 on page 291.
2. From the Security and Services menu, type 4 to select Access Control
Lists.
The Access Control Lists (ACL) menu is shown in Figure 100 on page
311.
1. From the Access Control Lists (ACL) menu, type 4 to selection Show
ACLs.
An example of the Show ACLs window is illustrated in Figure 104.
Figure 104. Show ACLs Menu
This menu is for viewing purposes only. To modify an ACL, refer to
“Modifying an ACL” on page 314. The columns in the display are
explained here:
ˆ ACL ID - The ACL’s ID number.
ˆ Description - The description of the ACL.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show ACLs
Number of ACLs: 12
ID
Description Active
-------------------------------------------------------
1
IP - deny Yes
2 HTTP - permit Yes
3 TCP - deny No
4 Src22.49 - deny Yes
5 P-149.22.22.22 Yes
6 Dst22.50 Yes
7 ARP packets - deny No
D - Detail ACL Display
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
