Chapter 17: Quality of Service
358 Section II: Advanced Operations
Displaying Flow
Groups
To display flow groups, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 87 on page 291.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 116 on page
352.
3. From the Quality of Service (QoS) menu, type 1 to select Flow Group
Configuration.
The Flow Group Configuration menu is shown in Figure 117 on page
353.
4. From the Flow Group Configuration menu, type 4 to select Show Flow
Groups.
The Show Flow Groups menu is shown in Figure 121.
Figure 121. Show Flow Groups Menu
The Show Flow Groups menu provides the following information:
ID
The flow group’s ID number.
Description
A description of the flow group.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show Flow Groups
Number of Flow Groups: 5
Parent
ID Description Traffic Class ID Active
------------------------------------------------------------
0
Dev database 22 Yes
1 Inv database 5 No
2 Video1 14 Yes
3 Video2 2 Yes
4 Demo dev 1 Yes
D - Display Flow Group Details
U - Update Display
R - Return to Previous Menu
Enter your selection?
