Chapter 19: IGMP Snooping
400 Section III: IGMP Snooping, MLD Snooping, and RRP Snooping
Displaying a List of Multicast Routers
A multicast router is a router that is receiving multicast packets from a
multicast application and transmitting the packets to host nodes. You can
use the AT-S63 management software to display a list of the multicast
routers that are connected to the switch.
To display a list of the multicast routers, perform the following procedure:
1. From the Main Menu, type 6 to select Advanced Configuration.
The Advanced Configuration menu is shown in Figure 137 on page
394
2. From the Advanced Configuration menu, type 2 to select IGMP
Snooping Configuration.
The IGMP Snooping Configuration menu is shown in Figure 138 on
page 395.
3. From the IGMP Snooping Configuration menu, type 7 to select View
IGMP Multicast Routers List.
The View IGMP Multicast Routers List menu is shown in Figure 140.
Figure 140. View IGMP Multicast Routers List Menu
The View IGMP Multicast Routers List menu displays a table that
contains the following columns of information:
VLAN
The VID of the VLAN in which the port is an untagged member.
Port/Trunk ID
The port on the switch where the multicast router is connected. If the
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
View IGMP Multicast Routers List
VLAN Port/Trunk ID RouterIP
----------------------------------------------------
1
14/- 172.16.01.1
U - Update Display
R - Return to Previous Menu
Enter your selection?
