Chapter 17: Quality of Service
366 Section II: Advanced Operations
The Modify Traffic Class menu is shown in Figure 125.
Figure 125. Modify Traffic Class Menu
6. Modify the settings as needed. For parameter definitions, refer to
“Creating a Traffic Class” on page 361.
When you modify a traffic class, note the following:
ˆ You cannot change the traffic class ID number.
ˆ To delete a value from a variable so as to leave it blank, select the
variable and then use the backspace key to delete its default
value.
ˆ Specifying an invalid value for a parameter that already has a
value causes the parameter to revert to its default value.
7. Type M to select Modify Traffic Class.
8. To modify another traffic class, repeat this procedure starting with step
4. To assign the traffic class to a policy, go to “Managing Policies” on
page 371.
9. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Modify Traffic Class
1 - Traffic Class ID .......... 0
2 - Description ............... Video2
3 - Exceed Action ............. Drop
4 - Exceed Remark Value ....... 0
5 - DSCP value ................ 0
6 - Max bandwidth ............. 0
7 - Burst Size ................ 0
8 - Priority .................. 0
9 - Remark Priority ........... No
A - ToS .......................
B - Move ToS to Priority ...... No
D - Move Priority to ToS ...... No
E - Flow Group List ...........
M - Modify Traffic Class
R - Return to Previous Menu
Enter your selection?
