AT-S63 Management Software Menus Interface User’s Guide
Section V: Spanning Tree Protocols 541
Displaying STP
Port Settings
To display STP port settings, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Configuration.
The Spanning Tree Configuration menu is shown in Figure 178 on
page 535.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The STP menu is shown in Figure 179 on page 537.
3. From the STP menu, type P to select STP Port Parameters.
The STP Port Parameters menu is shown in Figure 180 on page 539.
4. From the STP Port Parameters menu, type 2 to select Display STP
Port Configuration.
The Display STP Port Configuration menu is shown in Figure 182.
Figure 182. Display STP Port Configuration Menu
The Display STP Port Configuration menu displays a table that
contains the following columns of information:
Port
The port number.
State
Current state of the port. The possible states are Enabled or Disabled.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display STP Port Configuration
Port State Cost Priority
-------------------------------------------------------
1
Enabled Auto-Update 128
2 Enabled Auto-Update 128
3 Enabled Auto-Update 128
4 Enabled Auto-Update 128
5 Enabled Auto-Update 128
6 Enabled Auto-Update 128
7 Enabled Auto-Update 128
8 Enabled Auto-Update 128
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
