Chapter 8: Static and LACP Port Trunks
174 Section I: Basic Features
The following prompt is displayed:
Enter Aggregator Name [Max up to 20 alphanumeric
characters]:
5. Enter the name of the aggregator you want to delete. The name is
case-sensitive. You can delete only one aggregator at a time.
Are you sure you want to delete this aggregator (Y/N) [Yes/No]
->
6. Type Y to delete the aggregator or N to cancel the procedure.
If you entered Yes, the aggregator is deleted.
Configuring
LACP Port
Parameters
This procedure explains how to configure a port’s priority value. This
parameter determines whether a port is active or in standby mode as part
of an aggregate trunk. For further information, refer to “LACP Port Priority
Parameter” on page 153. This procedure also shows how to assign a port
to a different aggregator.
Note
To remove a port from an aggregator without assigning it to a
different one, skip this procedure and instead perform “Modifying an
Aggregator” on page 171. When modifying the aggregator, reenter
its port list, omitting the port you want to remove.
To configure a port, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 25 on page 112.
2. From the Port Configuration menu, type 4 to select Port Trunking and
LACP.
The Port Trunking and LACP menu is shown in Figure 42 on page 160.
3. Type 2 to select LACP Configuration.
The LACP (IEEE 8023ad) Configuration menu is shown in Figure 46
on page 167.
4. Type 4 to select Modify Aggregator.
