Chapter 16: Class of Service
332 Section II: Advanced Operations
Configuring Egress Scheduling
This procedure explains how to select and configure a scheduling method
for Class of Service. Scheduling determines the order in which the ports
handle packets in their egress queues. For an explanation of the two
scheduling methods, refer to “Scheduling” on page 324. Scheduling is set
at the switch level. You cannot set this on a per-port basis.
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 87 on page 291.
2. From the Security and Services menu, type 5 to select Class of
Service (CoS).
The Class of Service (CoS) menu is shown in Figure 106 on page 328.
3. From the Class of Service (CoS) menu, type 3 to select Configure
Egress Scheduling.
The Configure Egress Scheduling menu is shown in Figure 109.
Figure 109. Configure Egress Scheduling Menu
4. Type 1 to toggle Scheduling Mode between its two possible settings.
The default setting is Strict Priority.
If you select Strict Priority, skip the next step. Options 2 through 9 in
the menu do not apply to Strict Priority scheduling.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Configure Egress Scheduling
1 - Scheduling Mode ............ Strict Priority
2 - Queue 0 Weight ............. 0
3 - Queue 1 Weight ............. 0
4 - Queue 2 Weight ............. 0
5 - Queue 3 Weight ............. 0
6 - Queue 4 Weight ............. 0
7 - Queue 5 Weight ............. 0
8 - Queue 6 Weight ............. 0
9 - Queue 7 Weight ............. 0
R - Return to Previous Menu
Enter your selection?
