AT-S63 Management Software Menus Interface User’s Guide
Section V: Spanning Tree Protocols 585
The MSTP Port Parameters menu is shown in Figure 199.
Figure 199. MSTP Port Parameters Menu
4. From the MSTP Port Parameters menu, type 1 to select Configure
Generic Port Settings.
The following prompt is displayed:
Start port to configure: [1 to 26] ->
5. Enter the number of the port you want to configure. To configure a
range of ports, enter the first port of the range.
The following prompt is displayed:
End port to configure: [1 to 26] -> 4
6. Enter the last port of the range. To configure just one port, enter the
same port here as in Step 5.
The Configure MSTP Port Settings menu is shown in Figure 200.
Figure 200. Configure MSTP Port Settings Menu
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
MSTP Port Parameters
1 - Configure Generic Port Settings
2 - Configure Per Spanning Tree Port Settings
3 - Display MSTP Port Configuration
4 - Display MSTP Port State
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Configure Generic Port Settings
1 - Port External Path Cost ..... Auto
2 - Point-to-Point .............. Auto Detect
3 - Edge Port ................... Yes
R - Return to Previous Menu
Enter your selection?
