AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 367
Deleting a Traffic
Class
To delete a traffic class, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 87 on page 291.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 116 on page
352.
3. From the Quality of Service (QoS) menu, type 2 to select Traffic Class
Configuration.
The Traffic Class Configuration menu is shown in Figure 123 on page
361.
4. From the Traffic Class Configuration menu, type 3 to select Destroy
Traffic Class. The following prompt is displayed:
Available Traffic Class(es): 0-7
Enter Traffic Class ID : [0 to 511] -> 0
5. Enter the ID number of the traffic class you want to delete. You can
delete only one traffic class at a time.
The Destroy Traffic Class menu is shown in Figure 126.
Figure 126. Destroy Traffic Class Menu
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Destroy Traffic Class
1 - Traffic Class ID .......... 0
2 - Description ............... Video2
3 - Exceed Action ............. Drop
4 - Exceed Remark Value ....... 0
5 - DSCP value ................ 0
6 - Max bandwidth ............. 0
7 - Burst Size ................ 0
8 - Priority .................. 0
9 - Remark Priority ........... No
A - ToS .......................
B - Move ToS to Priority ...... No
D - Move Priority to ToS ...... No
E - Flow Group List ...........
D - Destroy Traffic Class
R - Return to Previous Menu
Enter your selection?
