AT-S63 Management Software Menus Interface User’s Guide
Section VII: Port Security 717
Displaying Port Security Levels
To view the current security levels and intrusion actions for the ports on
the switch, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 25 on page 112.
2. From the Port Configuration menu, type 5 to select Port Security.
The Port Security menu is shown in Figure 244 on page 713.
3. From the Port Security menu, type 2 to select Display Port Security.
The Display Port Security menu is shown in Figure 247.
Figure 247. Display Port Security Menu
The Display Port Security menu displays a table that contains the
following columns of information:
Port
The number of the port.
Security Mode
The active security mode on the port.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display Port Security
Port Security Mode Threshold Intruder Action Participating
--------------------------------------------------------------
1
Limited 6 Trap Yes
2 Limited 10 Trap Yes
3 Automatic --- ------ ---
4 Locked --- ------ ---
5 Automatic --- ------ ---
6 Automatic --- ------ ---
7 Automatic --- ------ ---
8 Secured --- ------ ---
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
