Chapter 29: MAC Address-based VLANs
704 Section VI: Virtual LANs
Protocol
The protocol associated with this VLAN. The possible settings are:
Blank - The VLAN is a port-based, tagged, or MAC address-based
VLAN.
GARP - The VLAN is a dynamic GVRP VLAN or the port is a dynamic
GVRP port of a static VLAN.
Untagged (U) / Tagged (T)
The untagged and tagged ports of a VLAN. These are empty for a
MAC address-based VLAN.
3. To view the MAC addresses and egress ports of a MAC address-
based VLAN, type D to select Detail Information Display.
The following prompt is displayed:
Enter VLAN ID [2 to 4094] -> 2
4. Enter the VID of the MAC address-based VLAN whose details you
want to view.
The Detail Information Display menu is shown in Figure 243.
Figure 243. Detail Information Display
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Detail Information Display
VID VLAN Name VLAN Type Protocol Untagged (U) / Tagged (T)
----------------------------------------------------------------------
2 Sales MAC Based U:
T:
MAC Associations:
Total number of associated MAC addresses: 5
-------------------------------------------------
MAC Address
Ports
-------------------------------------------------
00:0A:22:22:22:22
12-20,22
00:0A:44:44:44:44 12
00:0A:66:66:66:66 12
00:0A:77:77:77:77 12
00:0A:88:88:88:88 12
U - Update Display
R - Return to Previous Menu
Enter your selection?
