Chapter 25: Port-based and Tagged VLANs
618 Section VI: VLANs
Example of Creating a Tagged VLAN
The following procedure creates the Engineering VLAN in the top switch
illustrated in “Tagged VLAN Example” on page 610. This VLAN will be
assigned a VID of 3. It will consist of four untagged ports, ports 9, 11 to 13,
and two tagged ports, ports 2 and 10.
To create the example Engineering VLAN, perform the following
procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 207 on page 612.
2. From the VLAN Configuration menu, type 4 to select Configure
VLANs.
The Configure VLANs menu is shown in Figure 208 on page 613.
3. From the Configure VLANs menu, type 1 to select Create VLAN.
The Create VLAN menu is shown in Figure 209 on page 613.
4. From the Create VLAN menu, type 1 to select VLAN Name and enter
“Engineering”.
5. Type 2 to select VLAN ID (VID) and enter “3”. This is the VID value for
the new VLAN.
6. Type 3 to toggle VLAN Type to Port Based.
7. Type 4 to select Tagged Ports and enter “2,10”. These are the tagged
ports of the VLAN on the switch.
8. Type 5 to select Untagged Ports and enter “9,11-13”. These are the
untagged ports of the VLAN.
Note
Option 6, Protected Ports, must be left in the “No” default setting
when creating a port-based or tagged VLAN. This option is
explained in Chapter 28, “Protected Ports VLANs” on page 671.
9. Type C to select Create VLAN.
10. After the switch displays the prompt notifying you that it created the
VLAN, press any key.
The new Engineering VLAN has now been created.
