Description Item
Opens the Add Hosts window Add Hosts
Opens the Remove Hosts window. Remove Hosts*
Opens the Add Hosts window. Add Hosts
Opens a window where you can export configuration information listed in the
table to a file that can be used for multiple purposes, such as backup or reporting. Export
Available by clicking More Actions.
LUNs tab
This tab provides information about the LU paths that correspond to the LDEV assigned to the
logged-in user.
Description Item
Identifier of the port. Port ID
Icons and identifiers of the logical unit. Clicking a LUN ID opens the LUN
Properties window. LUN ID
Identifier OF the LDEV. LDEV ID
Name of the LDEVs. LDEV Name
Emulation types for each logical volume (or logical device). For LUSE volumes,
an asterisk (*) and a number appear on the right of the emulation type. For
example, OPEN-9*3 indicates that three OPEN-9 volumes are combined. Emulation Type
Size of each logical volume. Capacity
Provisioning type of the logical volume. Provisioning Type
•
Basic: Internal volume.
• External: External volume.
•
THP: THP V-VOL.
•
Snapshot: Snapshot volumes
Attribute for the LDEV. Attribute
•
Command Device: The volume is a command device.
•
Remote Command Device: The volume is a remote command device.
• System Disk: The volume is a system disk.
•
JNL VOL: The volume is a journal volume.
• Pool VOL: The volume is a pool volume. The number in the parenthesis shows
the pool identifier.
•
Reserved VOL: The volume is a reserved volume.
• Quorum Disk: The volume is a quorum disk.
•
Hyphen (-): Volume other than the above.
Total number of the relevant paths and the alternative paths. Number of Paths
Opens the Add LUN Paths window. Add LUN Paths
Opens the Copy LUN Path window. Copy LUN Paths
Opens the Edit Command Devices window. Edit Command Devices
Opens the Delete LUN Paths window. Delete LUN Paths*
Opens the Edit UUIDs window. Edit UUIDs*
300 LUN Manager GUI reference
