Description Item
Indicates whether the cache mode is enabled. If the LDEV is not an external
volume, a hyphen (-) appears. Cache Mode
Location of the LDEV in the pool-VOL. Location
Top indicates the LDEV is the top pool-VOL.
Resource group name and identifier of the LDEV. Resource Group Name (ID)
Designates a selected pool-VOL as the top pool-VOL in this pool. Every pool
must have a top pool-VOL. The top pool-VOL contains system information and
cannot be moved to another volume and can never be deleted. Change Top Pool VOL
From the Selected Pool Volumes table, select the pool-VOL a row and then click
it. The selected pool-VOL will be changed to the top pool-VOL.
When expanding a pool, this button is disabled and you cannot designate the
top pool-VOL.
Reclaim Zero Pages window
Description Item
LDEV identifier. LDEV ID
LDEV name. LDEV Name
Nickname and identifier of the pool. Pool Name (ID)
Emulation type. Emulation Type
Capacity of the pool. Capacity
Provisioning type configured for this LDEV. Provisioning Type
For Thin Provisioning or Smart Tiers, THP appears.
Reclaim Zero Pages window 279
