Summary
Description Item
WWN of the port. Internal WWN
Data transfer speed for the selected fibre channel port in the unit of Gbps (Gigabit
per second). Speed
LUN security setting (enable or disable) on the port. Security
Attribute of the port indicating I/O flow. Attribute
• Initiator: Issues I/O commands to a target port when I/O is executed between
storage systems with Continuous Access Synchronous, and so on.
•
Target: Receives I/O commands from a host.
•
RCU Target: Receives I/O commands from an initiator when I/O is executed
between storage systems with Continuous Access Synchronous, and so on.
•
External: Issues I/O commands to a target port of an external storage system
with External Storage.
Address of the selected port. Address (Loop ID)
Indicates whether a fabric switch is used. FC Switch
Topology of the selected port. Connection Type
Total number of logical units set to the relevant port, and the maximum number
of logical units that can be registered to the port. When an initiator port or
external port is selected, a hyphen (-) appears. Number of LUNs
Total number of hosts set to the relevant port, and the maximum number of hosts
that can be registered to the port. When an initiator port or external port is
selected, a hyphen (-) appears. Number of Hosts
Total number of host groups set to the relevant port, and the maximum number
of host groups that can be registered to the port. When an initiator port or
external port is selected, the maximum number is not available. Number of Host Groups
Host Groups tab
This tab provides information about the host groups assigned to the logged-on user.
Description Item
Identifier of the port. Port ID
Icons and names of host groups. Host Group Name
Clicking a host group name opens the host group information window.
Host mode of the host group. Host Mode
LUN security setting (enable or disable) on the port. Port Security
Number of hosts in the host group. Number of Hosts
Number of logical units in the host group. Number of LUNs
Resource group name and ID of the host group. Resource Group Name (ID)
Opens the Create Host Groups window. Create Host Groups
Opens the Add LUN Paths window. Add LUN Paths
Opens the Add Hosts window. Add Hosts
Opens the Delete Host Groups window. Delete Host Groups*
Port/Host Groups window after selecting a port under Ports/Host Groups 297
