In the matrix, cells of used LDEV numbers display in blue, unselectable in gray, and unused in
white. The LDEV numbers corresponding to any one of the following conditions cannot be specified:
•
LDEV is already in use.
•
LDEV is already assigned to another emulation group (grouped every 32 LDEVs).
•
LDEV is not assigned to the user.
Description Item
Emulation type selected in the Create LDEVs window. See “Emulation groups
and types” (page 222) for a list.
Emulation Type
LDEV identifier, which is the combination of LDKC, CU, and LDEV. LDEV IDs
LDKC: Indicates the LDKC number.
CU: Indicates the CU number.
Emulation groups and types
The following table shows the emulation groups and emulation types.
D-type (Overseas PCM) emulation type Emulation group
OPEN-3, OPEN-8, OPEN-9, OPEN-E Group 4
None Group 5
OPEN-V Group 6
222 LDEV GUI reference
