Setting the fibre channel port address
When configuring your storage system, set addresses for fibre channel ports. When addressing
fibre channel ports, use AL-PA (arbitrated-loop physical address) or loop IDs as the addresses. See
“Addresses for fibre channel ports” (page 131)
for information about available addresses.
NOTE:
In Fibre Channel over Ethernet networks, you do not need to set the address of a fibre
channel port.
1.
In the Storage Systems tree, click Ports/Host Groups.
2.
In the Ports/Host Groups window, select the Ports tab.
3.
Select the desired port.
4.
Select Edit Ports.
5.
In the Edit Ports window, select the Address (Loop ID) check box, and then select the address.
6.
Click Finish.
7.
In the Confirm window, confirm the settings, in Task Name type a unique name for this task
or accept the default, and then click Apply.
If Go to tasks window for status is checked, the Tasks window opens.
Addresses for fibre channel ports
The following addresses are available for setting fibre channel ports.
Loop ID
(120~125)
AL-PA
Loop ID
(90~119)
AL-PA
Loop ID
(60~89)
AL-PA
Loop ID
(30~59
AL-PA
Loop ID
(0~29)
AL-PA
120
10
90
49
60
76
30
B4
0
EF
121
0F
91
47
61
75
31
B3
1
E8
122
08
92
46
62
74
32
B2
2
E4
123
04
93
45
63
73
33
B1
3
E2
124
02
94
43
64
72
34
AE
4
E1
125
01
95
3C
65
71
35
AD
5
E0
-
-
96
3A
66
6E
36
AC
6
DC
-
-
97
39
67
6D
37
AB
7
DA
-
-
98
36
68
6C
38
AA
8
D9
-
-
99
35
69
6B
39
A9
9
D6
-
-
100
34
70
6A
40
A7
10
D5
-
-
101
33
71
69
41
A6
11
D4
-
-
102
32
72
67
42
A5
12
D3
-
-
103
31
73
66
43
A3
13
D2
-
-
104
2E
74
65
44
9F
14
D1
-
-
105
2D
75
63
45
9E
15
CE
-
-
106
2C
76
5C
46
9D
16
CD
-
-
107
2B
77
5A
47
9B
17
CC
-
-
108
2A
78
59
48
98
18
CB
-
-
109
29
79
56
49
97
19
CA
