Description Item
Opens the Shred LDEVs window. Shred LDEVs*
Opens the Block LDEVs window. Block LDEVs*
Opens the Restore LDEVs window. Restore LDEVs*
Opens a window where you can export configuration information listed in the table to a file
that can be used for multiple purposes, such as backup or reporting. Export
*Available when you click More Actions.
Window after selecting Logical Devices
Use this window to view information about logical devices. Only the LDEVS assigned to the
logged-on user are available.
•
“Summary”
•
“LDEVs tab”
Summary
Description Item
Number of allocated LDEVs for open system. Open Allocated
Number of unallocated LDEVs for open system. Open Unallocated
Number of reserved LDEVs for the open system. Open Reserved
Number of allocated V-VOLs for the open system. Open V-VOLs
Number of allocated LDEVs for the mainframe system. Mainframe Allocated
Number of reserved LDEVs for the mainframe system. Mainframe Reserved
208 LDEV GUI reference
