Parity Groups table
Description Item
Parity group IDs. Parity Group ID
Capacity of each parity group. Capacity
Number of LDEVs in each parity group. Number of LDEVs
Total number of selected parity groups. Total
LDEVs table
Description Item
LDEV IDs. LDEV ID
Some undefined LDEV IDs may appear. A hyphen in the LDEV name indicates the LDEV
is undefined.
LDEV names. LDEV Name
Parity group ID where the LDEV belongs. Parity Group ID
Pool name and ID where the LDEV belongs. Pool Name (ID)
Capacity of each LDEV. Capacity
Provisioning type of a volume. Provisioning Type
•
Basic: Internal volume
• THP: V-VOLs of Thin Provisioning
•
External: External volume
• Snapshot: Snapshot volume
Attribute of the volume indicating how the LDEV is being used. Attribute
•
Command Device: Command device
• Remote Command Device: Remote command device
•
System Disk: System disk
• JNL VOL: Journal volume
•
Pool VOL: Pool volume. The number in parentheses is the pool identifier.
•
Reserved VOL: Reserved volume
• Quorum Disk: Quorum disk
•
-: Volumes other than the above ones
Journal group ID when the attribute is JNL VOL. A hyphen indicates the attribute is other
than JNL VOL. Journal Group ID
Total number of selected volumes. Total
Ports table
Description Item
Port IDs. Port Name
Attribute of the port indicating I/O flow. Attribute
•
Initiator: Issues I/O commands to a target port when I/O is executed between storage
systems with Continuous Access Synchronous, and so on.
• Target: Receives I/O commands from a host.
200 Resource Partition GUI reference
