View Physical Location window
Use this window to view information about the physical location of where free spaces and LDEVS
are assigned in a parity group.
Parity Group Property table
Description Item
Parity group identifier. For an interleaved parity group, all parity groups that
are contained in the interleaved parity group are shown. Parity Group ID
RAID level. An asterisk "*" indicates that the parity group to which the LDEV
belongs is interleaved (concatenated). RAID Level
Free capacity and total capacity of the parity group. Capacity (Free/Total)
Drive type and rpm in use on this LDEV. Drive Type/ RPM
For external volumes, vendor name, model name, and serial number appear.
For internal volumes, -/-/- appears. Vendor/Model/Serial Number
Resource group name and ID of which this parity group is a member. Resource Group Name (ID)
Physical Location table
Description Item
Location where the free spaces and LDEVs are assigned. Physical Location No.
Free space number. The hyphenation appears for volumes other than free spaces. Free Space No.
LDEV identifier. A hyphen (-) appears for other than LDEV IDs. LDEV ID
LDEV name. A hyphen (-) appears for volumes other than LDEVs. LDEV Name
Emulation type. A hyphen (-) appears for volumes other than LDEVs. Emulation Type
View Physical Location window 223
