8.3.2 Mounting plate, field housing
Dimensions in mm and inch
8.3.3 Mounting plate, wall-mounted housing
Dimensions in mm and inch
[mm] [inch]
a 60 2.4
b 100 3.9
c Ш9 Ш0.4
[mm] [inch]
a Ш9 Ш0.4
b 64 2.5
c 16 0.6
d 6 0.2
e 63 2.5
f 4 0.2
g 64 2.5
h 98 3.85
