6.5.13 Diagnosis values (menu C1.5.4...C1.5.6)
Selection of diagnosis values to appear on the display or to be programmed on the outputs.
6.5.14 Graphic page (menu C6.5)
With this converter, the trend of the main measurement can be graphically displayed. The first
measurement on display page 1 is always defined as the main measurement.
• Menu C6.5.1 defines the range for the trend indicator (manual or automatic).
• Menu C6.5.2 defines the range for manual setting.
• Menu C6.5.3 defines the time span for the trend indicator.
6.5.15 Save settings (menu C6.6.2)
This function allows all settings to be stored in a memory.
• Backup 1: Saves settings in backup memory area 1
• Backup 2: Saves settings in backup memory area 2
6.5.16 Load settings (menu C6.6.3)
This function allows the complete stored settings to be loaded again.
• Backup 1: Loading from backup - memory 1
• Backup 2: Loading from backup - memory 2
• Factory: Uploading the original factory settings
