Data Structures
7
gslbZoneSummary
This structure is the high-level description of GSLB zone.
hostDomainIP
This structure is the high-level description of domain IP configuration of GSLB host.
hostPort
This structure is the high-level description of port configuration in GSLB host.
startValue string Optional Start value in a range.
endValue string Optional End value in a range.
Name Type Presence Rules Description
name string The GSLB zone.
hostList gslbHost [ ] The host range.
dnsSec dnsSecModeEnum DNS SEC mode enumeration list.
TABLE 73 hostDomainIP structure
Name Type Presence Rules Description
ipAddress string Mandatory Domain IP address.
hashWeight unsignedInt Mandatory Value is in
percentage. Valid
range is from 0 to
100. Default
value is 1
percent. Assign hash weights to the IP
address.
TABLE 74 hostPort structure
Name Type Presence Rules Description
portNameOrNumber string Optional Valid value range is
from 1 to 65535.
"hostApplication"
and "portNumber"
parameters cannot
be present. Specifies the TCP or UDP port
number instead of a well-known
port. The GSLB ADX performs Layer
4 TCP or UDP health checks for the
ports but does not perform
application-specific health checks.
portTracking boolean Optional Default value is
“FALSE”. Configure the GSLB ADX to track a
particular application port for
active bindings if multiple
application ports are associated
with a domain.
TABLE 72 gslbZoneSimpleFilter structure
Name Type Presence Rules Description
