Data structures
4
VrrpInterfaceSummary
This structure is a high-level description of the VRRP interface.
VrrpInterfaceSummaryFilter
This structure is a high-level description of a VRRP interface summary filter.
VRID unsignedInt Optional VRID
state vrrpStateEnum Optional Init/Master/Backup
mode vrrpRouterTypeEnum Optional OWNER or BACKUP
maskBit unsignedInt
priority unsignedInt Optional 3-254 Master/Backup priority
helloInterval unsignedInt Optional 1-84
sec/60-36
00 sec Master/ backup router’s hello message
interval
deadInterval unsignedInt Optional 1-84 sec Backup router’s dead interval
advertiseBack twoWayToggleEnum Optional Enable a Backup to send Hello messages
trunkPort String Optional Configure the VRID on one interface to track
the link state
tracktrunkPort String Optional Configure the track-trunk-port on the
interface
trackPriority unsignedInt Optional Track priority
virtualIPAddress String Optional Virtual IP address
masterRouterIP String Optional Master router IP address
backupRouterIP String Optional Backup router IP address
expireTime String Optional Expire time
nextHelloSent String Optional Next hello message sent
backupPreempt twoWayToggleEnum Optional Enable/disable preemption on a backup
TABLE 775 Attributes
Members Type Presence Rules Description
type vrrpTypeEnum Mandatory VRRP type
interface InterfaceID Mandatory Interface on which the VRRP is
configured.
address address[] Optional IP address of the interface.
authType vrrpAuthenticationTypeEnum Optional NONE/
SIMPLE Authentication type.
TABLE 776 Attributes
Parameters Type Presence Rules Description
simpleFilter VrrpInterfaceSummarySimpleFilter Mandatory Simple filter field.
TABLE 774 Attributes
Members Type Presence Rules Description
