Data structures
6
StaticNatMapSimpleFilter
This structure is a high-level description of a simple filter for Static NAT mapping.
TcpProfile
This structure is a high-level description of the TCP profile.
TABLE 233 Attributes
Name Type Presence Rule Description
field staticNatMapFilterFieldEnum Mandatory Filter field name.
operator filterOperatorEnum Mandatory Filter operator type.
value string Optional Ignored when
“operator” value is
“RANGE”. Value of the field for filtering.
startValue string Optional This parameter is
mandatory and
considered only
when “operator”
value is “RANGE”. Start value in a range.
endValue string Optional This parameter is
mandatory and
considered only
when “operator”
value is “RANGE”. End value in a range.
TABLE 234 Attributes
Name Type Presence Rules Description
name string Mandatory Can be a maximum of
64 characters. Name of the TCP profile.
enableNagleAlgorithm boolean Optional The default value is
true. Enables or disables
Nagle’s algorithm.
enableDelayedAckAlgorithm boolean Optional The default value is
true. Enables or disables the
delayed ACK algorithm.
enablePushBit boolean Optional The default value is
true. Enables or disables the
PUSH flag setting.
tcpReceiveQueueSize unsignedInt Optional The default value is
zero bytes. The TCP receive queue size
in bytes.
tcpTransmitQueueSize unsignedInt Optional The default value is
zero bytes. The TCP transmit queue
size in bytes.
mss unsignedInt Optional The default value is
zero bytes. When
Jumbo is enabled, the
maximum allowed
value is 9176.
Otherwise maximum
allowed value is 1460. The TCP maximum
segment size.
