Data structures
5
RealServerPortConnStats
This structure is the high-level description of any real server port connection statistics.
TABLE 413 Attributes
Name Type Presence Rules Description
rsPort Server Optional RS port
runTimeState realServerAndPortStatusEnum Optional Run time state
currentConn unsignedInt Optional The number of client connections
that are currently on the real server
port.
totalConn unsignedInt Optional The total number of connections on
the real server port since the
Brocade Virtual ADX was booted.
rxPkts unsignedInt Optional The number of packets received by
the port from the server.
rxBytes unsignedLong Optional The number of bytes that the real
server port has received from the
server.
txPkts unsignedInt Optional The number of packets sent by the
port to the server.
txBytes unsignedLong Optional The number of bytes the real server
port has sent to the server.
applRTTms unsignedInt Optional Value
must be
in milli-
seconds. The application round-trip time, in
milliseconds.
tcpRTTms unsignedInt Optional Value
must be
in milli-
seconds. The TCP round-trip time, in
milliseconds.
currentTcpRtt unsignedInt Optional The current TCP round-trip time.
currentApplRtt unsignedInt Optional The current application round-trip
time.
adminStatus twoWayToggleEnum Optional The administrative state of the
server.
isBackup boolean Optional Specifies if a server is a backup
server.
portStatus RealServerPortStatus Optional The port status
rxPktsRate unsignedInt Optional Rx packets rate
txPktsRate unsignedInt Optional Tx packets rate
