Data structures
5
VirtualServerPortStatus
This structure is a high-level description of any virtual server port status.
VirtualServerPortSummary
This structure provides the summary details of the virtual server port.
VirtualServerPortSummaryFilter
This structure is a the high-level description of the filter for virtual server port summary.
TABLE 484 Attributes
Name Type Presence Rules Description
status predictorEnum [] Optional The state of the virtual server port.
adminState twoWayToggleEnum Optional The admin status.
TABLE 485 Attributes
Name Type Presence Rules Description
virtualServerPort Server Optional Specifies the virtual server-port.
adminState twoWayToggleEnum Optional Specifies the admin state of the
server
runTimeStatus virtualServerAndPortStatusEnum Optional Specifies the run time state of
the server
enableDsr boolean Optional Enables DSR.
enableSticky boolean Optional Enables sticky.
isConcurrent boolean Optional Specifies if the virtual server
port is concurrent
tcpOnly boolean Optional TCP only
udpOnly boolean Optional UDP only
Stateless boolean Optional Stateless
customHealthCheck string Optional Custom health check
currentConnection unsignedInt Optional Current connection
rxPkts unsignedInt Optional Rx packets
txPkts unsignedInt Optional Tx packets
rxPktsRate unsignedInt Optional Rate of Rx packets.
txPktsRate unsignedInt Optional Rate of Tx packets.
TABLE 486 Attributes
Name Type Presence Rules Description
simpleFilter VirtualServerPortSummarySimpleFilter Mandatory Simple filter for virtual server port
summary.
