Brocade Virtual ADX XML API Programmer’s Guide (Supporting ADX v03.1.00) - Manual (Page 501)

Brocade Virtual ADX XML API Programmer’s Guide 491
53-1003248-01
Data structures
5
maxConnection unsignedInt Optional The maximum TCP
connection rate. The
range is from 1 to
65535.
maxTCPConnRate unsignedLong Optional The maximum TCP
connection rate.
maxUDPConnRate unsignedLong Optional The maximum UDP
connection rate.The
range is from 1 to
65535.
enableDestinationNAT boolean Optional Enables the destination
NAT.
enableHWForwardPassThroughTraffic boolean Optional Enable the hardware
forward of the non SLB
traffic.
noReverseNAT boolean Optional Does not perform
reverse NAT even if it is
configured globally.
enableExceedMaxDrop boolean Optional Enable the exceed
maximum drop option.
bandWidthWeight unsignedInt Optional Valid from 1
to 5 The bandwidth metric
weight
byteRateThresold unsignedInt Optional Valid
between 1
and
214748364
7 Maximum byte rate
allowed for a real
server.
isAsymmetric boolean Optional Specifies whether the
real server is
asymmetric or not.
enableUseLearnedMACAddr boolean Optional Enable use learned
MAC address
leastConnectionWeight unsignedInt Optional Least connection
weight
hostRange unsignedInt Optional The range is
from 0 to
4096. Specifies the range of
the host.
predictorConfig PredictorConfiguration Optional Predictor configuration
hcTrackingMode trackingModeEnum Optional Health check tracking
mode
hcTrackPort L4Port Optional Health check track port
hcTrackPortList L4Port [ ] Optional Health check track port
list
TABLE 401 Attributes (Continued)
Name Type Presence Rules Description
