Brocade Virtual ADX XML API Programmer’s Guide (Supporting ADX v03.1.00) - Manual (Page 105)

Brocade Virtual ADX XML API Programmer’s Guide 95
53-1003248-01
Data structures
3
flash
This structure is the high-level description of the flash memory.
HABackupNodeConfiguration
This structure is the high-level description of a backup node configuration.
startValue string Optional This parameter is
mandatory and considered
only when “operator” value
is “RANGE”. Start value in a
range.
endValue string Optional This parameter is
mandatory and considered
only when “operator” value
is “RANGE”. End value in a range.
TABLE 236 Attributes
Name Type Required Rules Description
moduleName string Yes The name of the module.
primaryImage image Yes The details of the primary code.
secondaryImage image Yes The details of the secondary code.
configFlash memStoreBytes Yes The total, used, and available
memory space on the configuration
flash.
codeFlash memStore Yes The total, used, and available
memory space on the code flash
memory.
TABLE 237 Attributes
Name Type Required Rules Description
backupPort HAbackupPort Optional Identifies an ethernet backup port
configuration information.
backupGroupID unsignedInt Optional The valid
values
between 0
and 127. Identifies the backup group ID.
switchState haStatusEnum Optional Indicates whether this Brocade Virtual ADX
is the active Brocade Virtual ADX or the
standby.
backupRouterPorts HARouterPort [ ] Optional Router ports added to the device.
TABLE 235 Attributes
Parameters Type Presence Rules Description
