Brocade Virtual ADX XML API Programmer’s Guide 105
53-1003248-01
Data structures
3
networkInterface
This structure is a high-level description of a network interface.
PortList
This structure is a high-level description of Port list information.
RadiusServerConfiguration
This structure is a high-level description for identifying the RADIUS server to the Brocade Virtual
ADX
TABLE 257 Attributes
Parameters Type Presence Rules Description
type interfaceNameEnum Optional Interface type.
id string Optional Interface ID.
IP string Optional The IP address of the interface.
TABLE 258 Attributes
Parameters Type Presence Rules Description
portList InterfaceID [ ] Mandatory Only Ethernet port numbers are
allowed. Either portList or
portRange is mandatory. Specifies one or more port
numbers.
beginPortRange InterfaceID Optional If range is specified, then both
“portBeginRange” and
“portEndRange” are Mandatory. Begin port number.
endPortRange InterfaceID Optional If range is specified, then both
“portBeginRange” and
“portEndRange” are Mandatory. End port number.
TABLE 259 Attributes
Parameters Type Presence Rules Description
hostIP string Mandatory Only IPv4 address is
allowed.
This parameter specifies the
IP address of the RADIUS
server.
authenticationPor
t unsignedInt Optional This parameter’S
valid value ranges
between 0 and
65535.
If the parameter
value is empty, then
the default port
number 1645 is
considered. If the
port value is 0, then
the default value of
the port is assigned This parameter is the
authentication UDP port
number.
