Data structures
5
RealServerPortConfiguration
This structure is the high-level description of any real server port configuration.
isRemote boolean Optional Designates the real server as a
remote server in the Brocade
Virtual ADX.
isBackup boolean Optional Designates the real server to be a
backup server.
enableSourceNAT boolean Optional Enables source NAT on the real
server.
statistics RealServerConnStats Optional Information about server and
associated connection status
portMonitoringList RealServerPortMonitoringDetails [] Optional Information about port
monitoring on the real server.
leastConnectionWeight unsignedInt Optional The least rate of TCP traffic (per
second) encountered on the
device.
TABLE 412 Attributes
Name Type Presence Rules Description
serverPort ServerPort Optional The server port
adminState twoWayToggleEnum Optional The administrative state
of the real
server, which can be one
of the following:
•
Enable
•
Disable.
serverId unsignedInt Optional The range
is from
1024 to
1279. Identifies the real server.
groupId ServerGroup Optional The range
is from 0 to
1023. Identifies the server
group.
slowStartId unsignedInt Optional Identifies the slow start
list.
isBackup boolean Optional Designates the real
server port to be a
backup port.
enableClearSessionOnPortUp boolean Optional Clears the sessions when
the real server port
comes up.
enablePeriodicHealthCheck boolean Optional Enables the periodic
health check for the real
server.
TABLE 411 Attributes (Continued)
Name Type Presence Rules Description
