Data structures
5
RealServerGroupSummary
This structure is the high-level description of any real server group summary.
RealServerInfo
This structure is the high-level description of any real server.
RealServerMonitoringDetails
This structure is the high-level description of the monitoring details for a server.
startVal
ue string Optional This parameter is mandatory
and considered only when
"operator" value is "RANGE". Start value in a range.
startVal
ue string Optional This parameter is mandatory
and considered only when
"operator" value is "RANGE". End value in a range.
TABLE 409 Attributes
Name Type Presence Rules Description
groupName string Optional Real server group name.
realServers L4Port Optional List of real servers in a group.
TABLE 410 Attributes
Name Type Presence Rules Description
realServer Server Optional Real server
adminState twoWayToggleEnum Optional Admin state
currentConnections unsignedInt Optional Current connections
maxConnections unsignedInt Optional Maximum connections
healthCheckStatus realServerAndPortSta
tusEnum Optional Health check status
rxPkts unsignedInt Optional Rx packets
txPkts unsignedInt Optional Tx packets
ports L4Port [ ] optional ports
TABLE 411 Attributes
Name Type Presence Rules Description
realServer Server Optional Identifies a real server.
adminState twoWayToggleEnum Optional Real server admin state.
runTimeState realServerAndPortStatusEnum Optional Real server run time state.
macAddress string Optional MAC address.
Name Type Presence Rules Description
