Brocade Virtual ADX XML API Programmer’s Guide (Supporting ADX v03.1.00) - Manual (Page 521)

Brocade Virtual ADX XML API Programmer’s Guide 511
53-1003248-01
Data structures
5
ServerPort
This structure is a high-level description of server port.
serverSimpleFilter
This structure is the high-level description of a filter for a server.
SlowStartIdConfiguration
This structure is the high-level description of a slow start ID.
TABLE 460 Attributes
Name Type Presence Rules Description
srvr server Optional Maximum 48 characters. Name of the real server.
port L4Port Optional Maximum 48 characters Port details
TABLE 461 Attributes
Name Type Presence Rules Description
field serverFilterFieldEnum Mandatory The field name of the filter.
operator filterOperatorEnum Mandatory The operator type of the filter.
value string Optional Ignored when the
operator value is
RANGE. The value of the field to be filtered.
startValue string Optional This parameter is
mandatory and
considered only
when the operator
value is RANGE. The start value in a range.
endValue string Optional This parameter is
mandatory and
considered only
when the operator
value is RANGE. The end value in a range.
TABLE 462 Attributes
Name Type Presence Rules Description
listId unsignedInt Optional Valid from 1 to
1000000. Specifies the slow-start list Id.
rate1 unsignedInt Optional Valid from 1 to
1000000. Specifies the number of
connections per second allowed
for the port during
the first interval.
interval1 unsignedInt Optional Valid from 1 to
1000000. Specifies the length of the first
interval in seconds.
rate2 unsignedInt Optional Valid from 1 to
1000000. Specifies the number of
connections per second allowed
for the port during the second
interval.
