Data structures
6
AclTraffic
This structure is a high-level description of Access Control list traffic information.
AclTrafficFilter
This structure is a high-level description of filter for the Access Control list traffic information.
AclTrafficSimpleFilter
This structure is a high-level description of simple filter for the Access Control list traffic
information.
TABLE 251 Attributes
Name Type Presence Rules Description
protocol IpProtocol Optional The IP protocol (well known
name or protocol number).
inboundPacketsReceivedCount unsignedInt Optional The inbound packets received.
outboundPacketsReceivedCount unsignedInt Optional The outbound packets received.
inboundPacketsPermittedCount unsignedInt Optional The inbound packets permitted.
outboundPacketsPermittedCount unsignedInt Optional The outbound packets permitted.
inboundPacketsDeniedCount unsignedInt Optional The inbound packets denied.
outboundPacketsDeniedCount unsignedInt Optional The outbound packets denied.
TABLE 252 Attributes
Name Type Presence Rules Description
simpleFilter AclTrafficSimpleFilter Mandatory The filter field name.
TABLE 253 Attributes
Name Type Presence Rules Description
field aclSummaryFilterFieldEnum Mandatory The filter field name.
operator filterOperatorEnum Mandatory The filter operator type.
value String Optional Ignored when the
value of the
operator
parameter is
RANGE. Value of the field for filtering.
startValue String Mandatory This parameter is
considered only
when the operator
parameter value is
RANGE. The start value in a range.
endValue String Mandatory This parameter is
considered only
when the operator
parameter value is
RANGE. The end value in a range.
