Brocade Virtual ADX XML API Programmer’s Guide (Supporting ADX v03.1.00) - Manual (Page 287)

Brocade Virtual ADX XML API Programmer’s Guide 277
53-1003248-01
Data structures
4
OspfArea
This structure is the high level description of OSPF area configurations.
OspfAreaConfigInfo
This structure is a high-level description of OSPF area configurations.
advReachableTime unsignedInt Mandatory Neighbor discovery advertised
reachable time.
retransmitIntervalTime unsignedInt Mandatory Neighbor discovery retransmit
interval.
advRetransmitIntervalTime unsignedInt Mandatory Neighbor discovery advertised
retransmit.
routerAdvertismentInterval unsignedInt Mandatory Neighbor discovery router
advertisements.
routerAdvertismentLiveInterval unsignedInt Mandatory Neighbor discovery router
advertisements live interval.
hopLimit unsignedInt
TABLE 685 Attributes
Members Type Presence Rules Description
versionFlag ipVersionEnum Mandatory Flag specifying the version
areaID string Mandatory Area number/Area IP
areaType ospfAreaTypeEnum Optional Area type
areaRange Address Optional 32 Area range
metric unsignedInt Optional The range is
from 1 through
16777215 Applicable for stub and NSSA
only
External route metric
noSummary boolean Optional Applicable only
to stub area Enable/Disable Summary LSA
defaultInformationOri
ginate boolean Optional Applicable only
for NSSA Enable/Disable default route
origination
advertise boolean Optional Enable/Disable advertise
TABLE 686 Attributes
Members Type Presence Rules Description
areaID string Mandatory The range is from 0
through 2147483647 Area ID/Area IP
areaType ospfAreaTypeEnum Optional Normal,Stub,NSSA Type of area
cost unsignedInt Optional The range is from 1
through 4294967, the
default is 100 Area cost
TABLE 684 Attributes
Members Type Presence Rules Description
