Data structures
4
VlanSimpleFilter
This structure is a high-level description of a simple VLAN filter.
VRIDConfig
This structure is a high-level description of the VRID configuration.
TABLE 768 Attributes
Name Type Presence Rules Description
field vlanFilterFieldEnum Mandatory Filter field name.
operator filterOperatorEnum Mandatory Filter operator type.
value string Optional Ignored when the "operator"
value is "RANGE". The value of the field for
filtering.
startValue string Mandatory This parameter is mandatory
and considered only when the
"operator" value is "RANGE".
Start value in a range.
endValue string Mandatory This parameter is mandatory
and considered only when the
"operator" value is "RANGE".
End value in a range.
TABLE 769 Attributes
Members Type Presence Rules Description
enabled twoWayToggleEnum Mandatory VRID enabled or disabled
type vrrpTypeEnum Mandatory VRRP type
interface InterfaceID Mandatory Interface on which VRRP configured
VRID unsignedInt Mandatory VRID
IP string Optional IPv4 or IPv6 address
enableGlobalUnic
ast boolean Optional VIP address can be global unicast address
or Linklocal address
state vrrpStateEnum Optional VRRP state for the VRID.
routerType vrrpRouterTypeEnum Optional OWNER or BACKUP
priority unsignedInt Optional 3-254 Master/Backup priority
helloInterval unsignedInt Optional 1-84
sec/60-3
600 sec Master/ backup router’s hello message
interval
deadInterval unsignedInt Optional 1-84 sec Backup router’s dead interval
advertiseBack twoWayToggleEnum Optional Enable a Backup to send Hello messages
trunkPort InterfaceID Optional Configure the VRID on one interface to track
the link state
tracktrunkPort InterfaceID Optional Configure the track-trunk-port on the
interface
trackPriority unsignedInt Optional Track priority
backupPreempt twoWayToggleEnum Optional Enable/disable preemption on a backup
