<11. Resource Block>
11-3
IM 21B04C01-01E
Hexadecimal
Indication
Indication
when Device
Description is
installed.
Meaning
0x00000008 Link
Obj.13/29/45
not open
The VCR* 1 to which link object
13, 29, or 45 is specified to be
linked is not open.
0x00000004 Link Obj.14
/30/46
not open
The VCR* 1 to which link object
14, 30, or 46 is specified to be
linked is not open.
0x00000002 Link
Obj.15/31/47
not open
The VCR* 1 to which link object
15, 31, or 47 is specified to be
linked is not open.
0x00000001 Link
Obj.16/32/48
not open
The VCR* 1 to which link object
16, 32, or 48 is specified to be
linked is not open.
*1: VCR: Virtual Coummunications Relationship
Table 11.4 DEVICE_STATUS_2 (without /EE)
Hexadecimal
Indication
Indication
when Device
Description is
installed.
Meaning
0x80000000
0x40000000
0x20000000
0x10000000
0x08000000
0x04000000
0x02000000
TB TRAVEL_
CALIB_RESULT
not Succeeded
Travel Calibration has not
been succeeded.
0x01000000 TB AUTO_
TUNE_RESULT
not Succeeded
Auto tuning has not been
succeeded.
0x00800000
0x00400000
0x00200000
OS BLOCK_ERR
not Zero
Block Error has occurred in
the OS block.
0x00100000 PID BLOCK_ERR
not Zero
Block Error has occurred in
the PID block.
0x00080000 DI2 BLOCK_ERR
not Zero
Block Error has occurred in
the DI2 block.
0x00040000 DI1 BLOCK_ERR
not Zero
Block Error has occurred in
the DI1 block.
0x00020000 AO BLOCK_ERR
not Zero
Block Error has occurred in
the AO block.
0x00010000 TB XD_ERROR
not Zero
XD Error has occurred in
the Transducer block.
0x00008000 TB in Signature
executing
Signature is proceeding.
0x00004000
0x00002000
0x00001000
PID in Bypass
active
Bypass is activated in PID
block.
0x00000800 DI2 in Simulate
active
SIMULATE is activated in
DI2 block.
0x00000400 DI1 in Simulate
active
SIMULATE is activated in
DI1 block.
0x00000200 AO in Simulate
active
SIMULATE is activated in
AO block.
0x00000100 TB in Auto tuning Auto tuning is proceeding.
0x00000080
0x00000040
0x00000020
OS in O/S mode OS block is in O/S mode.
0x00000010 PID in O/S mode PID block is in O/S mode.
0x00000008 DI2 in O/S mode DI2 block is in O/S mode.
0x00000004 DI1 in O/S mode DI1 block is in O/S mode.
0x00000002 AO in O/S mode AO block is in O/S mode.
0x00000001 TB in O/S mode TB block is in O/S mode.
