<1. Notes on Handling>
1-7
IM 21B04C01-01E
1.9.2 ATEX Certification
WARNING
• Do not open the cover when energized.
• When the ambient temp.≥70°C,
Use the heat-resisting cable≥90°C
• Take care not to generate mechanical
sparking when access to the instrument and
peripheral devices in hazardous locations.
• Electrostatic charge may cause an explosion
hazard.
Avoid any actions that cause the generation
of electrostatic charge, such as rubbing with
a dry cloth on coating face of product.
(1) Technical Data
A) ATEX Intrinsically Safe Type (Ex ia)
Caution for ATEX Intrinsically Safe Type.
NOTE
Keep the safety use conditions for both 1G and
1D when used in the hazardous gas and dust
area.
Note1. Model YVP110 Advanced Valve Positioner
with optional code /KS25 for potentially
explosive atmospheres:
• Applicable standard: EN60079-0:2006,
EN60079-11:2007, EN60079-26:2007,
EN60079-27:2006, EN61241-0:2006,
EN61241-1:2004, EN61241-11:2006 and
EN60529
• Certificate: KEMA 08ATEX0114 X
Note 2. Ratings
Type of Protection:
II 1G Ex ia IIB/IIC T4
II 1D Ex iaD 20 IP65 T100°C
II 1D Ex tD A20 IP65 T100°C
Maximum Surface Temperature for dust proof.:
T100°C
Ambient Temperature Ex ia or Ex iaD:
–40°C to +60°C
Ambient Temperature Ex tD: –40°C to +80°C
Ambient Humidity: 0 to 100%RH
(No condensation)
Degree of Protection of the Enclosure: IP65
Electrical Parameters:
For Ex ia IIC or Ex iaD
Ui = 24.0 V, Ii = 250 mA, Pi = 1.2 W,
Cint = 1.76 nF, Lint = 0 μH
or
For Ex ia IIB/ IIC or Ex iaD (FISCO model)
Ui = 17.5 V, Ii = 380 mA, Pi = 5.32 W,
Cint = 1.76 nF, Lint = 0 μH
For II 1D Ex tD
Input signal: 32 Vdc,
Output current: 17 mA
Note 3. Installation
All wiring shall comply with local installation
requirements.
(Refer to the installation diagram)
Note 4. Maintenance and Repair
The instrument modification or parts
replacement by other than authorized
representative of Yokogawa Electric
Corporation is prohibited and will void KEMA
Intrinsically safe Certification.
Note 5. Special Conditions for Safe Use
Because the enclosure of the Valve Positioner
is made of aluminium, if it is mounted in an area
where the use of category 1G apparatus is
required, it must be installed such, that, even in
the event of rare incidents, ignition sources due
to impact and friction sparks are excluded.
Once used as apparatus of equipment category
1D in type of protection Ex tD, the valve
positioner is no longer suitable as apparatus
of equipment category 1G or 1D in type of
protection Ex ia or Ex iaD.
Note 6. Installation Instructions
When used in a potentially explosive
atmosphere, requiring the use of apparatus of
equipment category 1D, suitable certified cable
entry devices or certified blanking elements
with a degree of ingress protection of at least
IP6X according to EN 60529 shall be used and
correctly installed.
Note 7. Installation
When used in potentially explosive atmosphere
for category 1D, need not use safety barrier.
