<9. Configuration>
9-9
IM 21B04C01-01E
Table 9.10
View Object for DI1, DI2 Function Block
Relative
index
Parameters
VIEW
1
VIEW
2
VIEW
3
VIEW
4
1
ST_REV
2
2
2
2
2
TAG_DESC
3
STRATEGY
2
4
ALERT_KEY
1
5
MODE_BLK
4
4
6
BLOCK_ERR
2
2
7
PV_D
2
2
8
OUT_D
2
2
9
SIMULATE_D
10
XD_STATE
2
11
OUT_STATE
2
12
GRANT_DENY
2
13
IO_OPTS
2
14
STATUS_OPTS
2
15
CHANNEL
2
16
PV_FTIME
4
17
FIELD_VAL_D
2
2
18
UPDATE_EVT
19
BLOCK_ALM
20
ALARM_SUM
8
8
21
ACK_OPTION
2
22
DISC_PRI
1
23
DISC_LIM
1
24
DISC_ALM
Total (in bytes)
22
8
22
19
Table 9.11
View Object for OS Function Block
Relative
index
Parameters
VIEW
1
VIEW
2
VIEW
3
VIEW
4
1
ST_REV
2
2
2
2
2
TAG_DESC
3
STRATEGY
2
4
ALERT_KEY
1
5
MODE_BLK
4
4
6
BLOCK_ERR
2
2
7
SP
5
5
8
OUT_1
5
5
9
OUT_2
5
5
10
OUT_1_RANGE
11
11
OUT_2_RANGE
11
12
GRANT_DENY
2
13
STATUS_OPTS
2
14
CAS_IN
5
5
15
BKCAL_OUT
5
16
IN_ARRAY
16
17
OUT_ARRAY
16
18
LOCKVAL
1
19
BKCAL_IN_1
5
20
BKCAL_IN_2
5
21
BAL_TIME
4
22
HYSTVAL
4
23
UPDATE_EVT
24
BLOCK_ALM
Total (in bytes)
28
26
43
48
