<11. Resource Block>
11-2
IM 21B04C01-01E
Hexadecimal
Indication
Indication
when Device
Description is
installed.
Meaning
0x00000080 Link Obj.9/25
not open
The VCR* 1 to which link object 9
or 25 is specified to be linked is
not open.
0x00000040 Link Obj.10
not open
The VCR* 1 to which link object
10 is specified to be linked is not
open.
0x00000020 Link Obj.11
not open
The VCR* 1 to which link object
11 is specified to be linked is not
open.
0x00000010 Link Obj.12
not open
The VCR* 1 to which link object
12 is specified to be linked is not
open.
0x00000008 Link Obj.13
not open
The VCR* 1 to which link object
13 is specified to be linked is not
open.
0x00000004 Link Obj.14
not open
The VCR* 1 to which link object
14 is specified to be linked is not
open.
0x00000002 Link Obj.15
not open
The VCR* 1 to which link object
15 is specified to be linked is not
open.
0x00000001 Link Obj.16
not open
The VCR* 1 to which link object
16 is specified to be linked is not
open.
*1: VCR: Virtual Coummunications Relationship
Table 11.3 DEVICE_STATUS_1 (with /EE)
Hexadecimal
Indication
Indication
when Device
Description is
installed.
Meaning
0x80000000
0x40000000
0x20000000
0x10000000
0x08000000
0x04000000 Abnormal
Boot Process
Abnormal boot process
0x02000000 Download fail Download fail
0x01000000 Download
incomplete
Download incomplete
0x00800000 Sim.enable
Jmpr On
The SIM.ENABLE switch on the
amplifier is set to ON.
0x00400000 RB in O/S
mode
The Resource block is in O/S
mode.
0x00200000
0x00100000
0x00080000 EEPROM
Failure
EEPROM failure
0x00040000
0x00020000
0x00010000
0x00008000 Link
Obj.1/17/33/49
not open
The VCR* 1 to which link object
1, 17, 33 or 49 is specified to be
linked is not open.
0x00004000 Link
Obj.2/18/34/50
not open
The VCR* 1 to which link object
2, 18, 34 or 50 is specified to be
linked is not open.
0x00002000 Link
Obj.3/19/35
not open
The VCR* 1 to which link object 3,
19, or 35 is specified to be linked
is not open.
0x00001000 Link
Obj.4/20/36
not open
The VCR* 1 to which link object 4,
20, or 36 is specified to be linked
is not open.
0x00000800 Link
Obj.5/21/37
not open
The VCR* 1 to which link object 5,
21, or 37 is specified to be linked
is not open.
0x00000400 Link Obj.6
/22/38
not open
The VCR* 1 to which link object 6,
22, or 38 is specified to be linked
is not open.
0x00000200 Link
Obj.7/23/39
not open
The VCR* 1 to which link object 7,
23, or 39 is specified to be linked
is not open.
0x00000100 Link
Obj.8/24/40
not open
The VCR* 1 to which link object 8,
24, or 40 is specified to be linked
is not open.
0x00000080 Link
Obj.9/25/41
not open
The VCR* 1 to which link object 9,
25, or 41 is specified to be linked
is not open.
0x00000040 Link
Obj.10/26/42
not open
The VCR* 1 to which link object 3,
19, or 35 is specified to be linked
is not open.
0x00000020 Link
Obj.11/27/43
not open
The VCR* 1 to which link object
11, 27, or 43 is specified to be
linked is not open.
0x00000010 Link
Obj.12/28/44
not open
The VCR* 1 to which link object
12, 28, or 44 is specified to be
linked is not open.
