<7. Standard Specifications>
7-3
IM 21B04C01-01E
Model and Suffix Codes
Model
Suffix Codes
Description
YVP110
. . . . . . . . . . . . . . . . . . . . . Valve positioner
Input Signal
-F . . . . . . . . . . . . . . . . . . .
Digital communication (F
OUNDATION
Fieldbus protocol)
Applicable Control
Valve
1 . . . . . . . . . . . . . . . . .
2 . . . . . . . . . . . . . . . . .
Single Acting Actuator
Double Acting Actuator
—
A . . . . . . . . . . . . .
Always A
Connections
1 . . . . . . . . . . .
3 . . . . . . . . . . .
5 . . . . . . . . . . .
6 . . . . . . . . . . .
Electrical Connection: G 1/2, Pneumatic Connection: Rc 1/4
Electrical Connection: 1/2 NPT, Pneumatic Connection: 1/4 NPT
Electrical Connection: DIN Pg 13.5, Pneumatic Connection: Rc 1/4
Electrical Connection: M20, Pneumatic Connection: Rc 1/4
—
N . . . . . . .
Always N
Optional Codes
/ . . . .
Optional Specifications
Optional Specifications
Item
Description
Code
Lightning protection
Power supply 9 to 32V DC
Allowable current Max. 6000 A(1× 40 μs), repeating 1000 A(1× 40 μs), 100 times
A
Painting
Coating change Epoxy resin coating
X1
Color change
Terminal Cover only
Munsell notation code: N1.5 Black
P1
Munsell notation code: 7.5BG4/1.5, jade green
P2
Metallic silver
P7
PID function
PID control function (one block)
LC1
PID control function (two blocks) *
7
LC2
Output monitor
Built-in output pressure sensor *
3
and signature function *
4
BP
With pressure gauge
Scale and calibration unit: Pa *
1
GP
Scale and calibration unit: kgf/cm
2
*
1
GM
Scale and calibration unit: bar *
1
GB
Scale and calibration unit: psi *
2
GE
Valve linkage
Two levers: stroke limit of 10 to 100 mm
LV1
One lever: stroke limit of 5 to 10 mm
When using this lever set, following performance specifications shall be applied;
Linearity:
Single Acting Actuator: ±1.0% of span, Double Acting Actuator: ±2.0% of span
Hysteresis:
Single Acting Actuator: 0.6% of span, Double Acting Actuator: 1.0% of span
LV2
High temperature use *
5
Ambient temperature limits: –10 to 85°C(14 to 185°F)
HT
Software download
function *
6
Based on Foundation Fieldbus Specification(FF-883)
Download class: Class1
EE
*1: Applicable for Connections code 1, 5 and 6.
*2: Applicable for Connections code 3.
*3: For double acting actuator, OUT1 connection is available.
*4: Single acting actuator type with /BP supports 5 types of signature functions.
*5: Applicable for double acting actuator.
*6: Not applicable for Option code FS15 and KS25.
*7: Applicable for option code EE.
