A-34
IM 21B04C01-01E
A4.9 System/Network Management VFD Parameters Relating to
Software Download
Table A4.5 System/Network Management VFD Parameters
Write Mode: R/W = read/write; R = read only
Index
(SM)
Parameter Name
Sub
Index
Sub-parameter Name
Default
(Factory Set)
Write
Mode
Remarks
400
DWNLD_PROPERTY
0
R
1
Download Class
1
2
Write Rsp Returned For
ACTIVATE
1
3
Write Rsp Returned For
PREPARE
1
4
Reserved
0
5
ReadyForDwnld Delay Secs 300
6
Activation Delay Secs
60
410
DOMAIN_DESCRIPTOR
0
R/W Read/write-
permitted only
for sub-index 1
1
Command
3
2
State
1
3
Error Code
0
4
Download Domain Index
440
5
Download Domain Header
Index
420
6
Activated Domain Header
Index
430
7
Domain Name
(Device name)
420
DOMAIN_HEADER.1
0
1
Header Version Number
0
2
Header Size
0
3
Manufacturer ID
4
Device Family
5
Device Type
6
Device Revision
0
7
DD Revision
0
8
Software Revision
9
Software Name
10
Domain Name
430
DOMAIN_HEADER.2
0
1
Header Version Number
1
2
Header Size
44
3
Manufacturer ID
0x594543
4
Device Family
(DEV_TYPE of RB)
5
Device Type
(DEV_TYPE of RB)
6
Device Revision
(DEV_REV of RB)
7
DD Revision
(DD_REV of RB)
8
Software Revision
(SOFT_REV of RB)
9
Software Name
ORIGINAL
10
Domain Name
(Device name)
440
DOMAIN
Read/write:
prohibited
Get-OD:
permitted
