Yokogawa YVP110 User Manual
Page 60
<9. Configuration>
9-10
IM 21B04C01-01E
Table 9.12
View Object for IS Function Block
Relative
index
Parameters
VIEW
1
VIEW
2
VIEW
3
VIEW
4
1
ST_REV
2
2
2
2
2
TAG_DESC
3
STRATEGY
2
4
ALERT_KEY
1
5
MODE_BLK
4
4
6
BLOCK_ERR
2
2
7
OUT
5
5
8
OUT_RANGE
11
9
GRANT_DENY
2
10
STATUS_OPTS
2
11
IN_1
5
5
12
IN_2
5
5
13
IN_3
5
5
14
IN_4
5
5
15
DISABLE_1
2
2
16
DISABLE_2
2
2
17
DISABLE_3
2
2
18
DISABLE_4
2
2
19
SELECT_TYPE
1
20
MIN_GOOD
1
21
SELECTED
2
2
22
OP_SELECT
2
2
23
UPDATE_EVT
24
BLOCK_ALM
25
IN_5
5
5
26
IN_6
5
5
27
IN_7
5
5
28
IN_8
5
5
29
DISABLE_5
2
2
30
DISABLE_6
2
2
31
DISABLE_7
2
2
32
DISABLE_8
2
2
Total (in bytes)
73
15
73
9
Table 9.13
View Objects of AR Function Block
Relative
index
Parameters
VIEW
1
VIEW
2
VIEW
3
VIEW
4
1
ST_REV
2
2
2
2
2
TAG_DESC
3
STRATEGY
2
4
ALERT_KEY
1
5
MODE_BLK
4
4
6
BLOCK_ERR
2
2
7
PV
5
5
8
OUT
5
5
9
PRE_OUT
5
5
10
PV_SCALE
11
11
OUT_RANGE
11
12
GRANT_DENY
2
13
INPUT_OPTS
2
14
IN
5
15
IN_LO
5
16
IN_1
5
17
IN_2
5
18
IN_3
5
19
RANGE_HI
4
20
RANGE_LO
4
21
BIAS_IN_1
4
22
GAIN_IN_1
4
23
BIAS_IN_2
4
24
GAIN_IN_2
4
25
BIAS_IN_3
4
26
GAIN_IN_3
4
27
COMP_HI_LIM
4
28
CONP_LO_LIM
4
29
ARITH_TYPE
1
30
BAL_TIME
4
31
BIAS
4
32
GAIN
4
33
OUT_HI_LIM
4
34
OUT_LO_LIM
4
35
UPDATE_EVT
36
BLOCK_ALM
Total (in bytes)
23
26
48
68
