A2.5 LM Parameters
A2.5.1 LM Parameter List
The tables below show LM parameters of a YVP positioner.
Meanings of Access column entries: RW = read/write possible; R = read only
Index
(SM)
Parameter Name Sub-parameter Name (Sub Index)
Default Factory
Setting
Access Remarks
362 DLME_LINK_MASTER_CAPABILITIES_VARIABLE 0x04 RW
363 DLME_LINK_
MASTER_INFO_
RECORD
0 RW
1 MaxSchedulingOverhead 0
2 DefMinTokenDelegTime 100
3 DefTokenHoldTime 300
4 TargetTokenRotTime 4096
5 LinkMaintTokHoldTime 400
6 TimeDistributionPeriod 5000
7 MaximumInactivityToClaimLasDelay 8
8 LasDatabaseStatusSpduDistributionPeriod 6000
364 PRIMARY_LINK_MASTER_FLAG_VARIABLE — RW LAS: True = 0xFF;
non-LAS: False = 0x00
365 LIVE_LIST_STATUS_ARRAY_VARIABLE — R
366 MAX_TOKEN_HOLD_
TIME_ARRAY
0 0x0000×16,
0x012c×16
RW
1 Element1 0x012c×5,
0x0000×27
2 Element2 0x0000×32
3 Element3 0x0000×32
4 Element4 0x0000×32
5 Element5 0x0000×32
6 Element6 0x0000×31 0x012c
7 Element7 0x012c×32
8 Element8 0x02
367 BOOT_OPERAT_FUNCTIONAL_CLASS As specified upon
ordering
RW 0x01 (basic device);
0x02 (LM)
368 CURRENT_LINK_
SETTING_RECORD
0 R Settings for LAS
1 SlotTime
2 PerDlpduPhlOverhead
3 MaxResponseDelay
4 FirstUnpolledNodeId
5 ThisLink
6 MinInterPduDelay
7 NumConseeUnpolledNodeId
8 PreambleExtension
9 PostTransGapExtension
10 MaxInterChanSignalSkew
11 TimeSyncClass
369 CONFIGURED_LINK_
SETTING_RECORD
0 RW
1 SlotTime 4095
2 PerDlpduPhlOverhead 4
3 MaxResponseDelay 5
4 FirstUnpolledNodeId 37
5 ThisLink 0
6 MinInterPduDelay 12
7 NumConseeUnpolledNodeId 186
8 PreambleExtension 2
9 PostTransGapExtension 1
10 MaxInterChanSignalSkew 0
11 TimeSyncClass 4
