A-5
IM 21B04C01-01E
Relative
Index Index
Parameter Name
Default
(factory setting)
Write Description [Setting range]
33 2033 POSITION_CHAR_
TYPE
1 O/S Defines the valve position-to-flow characteristics:
1 = linear
2 = equal % (50:1)
3 = equal % (30:1)
4 = quick open (inverse of 50:1 equal %)
5 = Camflex Percentage
255 = user-defined 10-segment function
34 2034 POSITION_CHAR 10, 20, 30, 40,
50, 60, 70, 80,
90
O/S Defines the coordinates of the segment function
when 255 is set for POSITION_CHAR_TYPE.
[0 to 100, only simple decreasing can be allowed]
35 2035 LIMSW_HI_LIM +110% Setting of high limit switch
36 2036 LIMSW_LO_LIM -10% Setting of low limit switch
37 2037 ELECT_TEMP — — Indicates the temperature on amplifier board
38 2038 TEMPERATURE_
UNIT
1001(degC) O/S Defines the unit of temperature indication above:
1001 = degC
1002 = degF
39 2039 SUPPLY_
PRESSURE
140kPa O/S Air supply pressure (irrespective of control)
40 2040 SPRING_RANGE 20kPa, 100kPa O/S Defines the pressure range and unit for valve
operation (with no direct effect on control).
The unit defined here also applies to OUT_
PRESSURE.
1133 = kPa
1137 = bar
1141 = psi
1145 = kgf/cm 2
41 2041 OUT_PRESSURE — — Output pressure to valve actuator
42 2042 SERVO_OUTPUT_
SIGNAL
— — Output current (%) to I/P module
43 2043 SERVO_RATE_GAIN
(*1)
5 O/S Derivative gain; a control parameter set by auto
tuning [ 2 to 20 ]
44 2044 SERVO_DEADBAND
(*1)
0.5% O/S Derivative action dead band; a control parameter
set by auto tuning [0 to 50%]
45 2045 SERVO_OFFSET
(*1)
55% of MV O/S Derivative action offset; a control parameter set by
auto tuning [0 to 100 % of MV]
46 2046 BOOST_ON_
THRESHOLD (*1)
1.9, 2.9% O/S Threshold for switching on boost action; a control
parameter set by auto tuning [0, 0.1 to 10 %]
47 2047 BOOST_OFF_
THRESHOLD (*1)
1.0, 1.0% O/S Threshold for switching off boost action; a control
parameter set by auto tuning [ 0.1 to 10%]
48 2048 BOOST_VALUE (*1) 8, 10% of MV O/S Boost value; a control parameter set by auto
tuning [ 0 to 50 % of MV]
49 2049 SERVO_I_SLEEP_
LMT (*1)
0 sec O/S Integral-action sleep timer setting; a control
parameter set by auto tuning [ 0 to10 sec]
50 2050 SERVO_P_ALPHA
(*1)
0 % O/S Multiplication coefficient for the square of
proportional factor; a control parameter set by
auto tuning [ 0 to 100%]
51 2051 INTERNAL_GAIN
(*1)(*2)
5 rad./mA O/S Gain for internal computation; a control parameter
set by auto tuning and travel calibration [ 0.5 to 50
rad./mA]
52 2052 MEAS_GAIN 0 rad./mA — Measurement gain of I/P module, control relay
and valve; a parameter set by auto tuning
53 2053 VALVE_TC 0 sec — Proportional factor of response speed of valve; a
parameter set by auto tuning
54 2054 VALVE_HYS 0 % — Hysteresis of valve actions (%); a parameter set
by auto tuning
55 2055 VALVE_SLIP_WIDTH 0 % — Slip width of valve actions (%); a parameter set by
auto tuning
56 2056 MEAS_PRESS_AIR 0kPa — Air pressure (%); a parameter set by auto tuning
(Valid when an optional pressure sensor is
specified.)
