A-17
IM 21B04C01-01E
Relative
Index Index
Parameter
Name
Valid
Range
Default
(factory
setting)
Write
Description
14
17514 IN
0
Input block
15
17515 IN_LO
0
Input for a low-range transmitter.
This is used for the range extension function.
16
17516 IN_1
0
Auxiliary input 1
17
17517 IN_2
0
Auxiliary input 2
18
17518 IN_3
0
Auxiliary input 3
19
17519 RANGE_HI
0
High limit for switching to a high-range transmitter by the
range extension function.
20
17520 RANGE_LO
0
Low limit for switching to a low-range transmitter by the
range extension function.
21
17521 BIAS_IN_1
0
IN_1 bias
22
17522 GAIN_IN_1
0
IN_1 gain
23
17523 BIAS_IN_2
0
IN_2 bias
24
17524 GAIN_IN_2
0
IN_2 gain
25
17525 BIAS_IN_3
0
IN_3 bias
26
17526 GAIN_IN_3
0
IN_3 gain
27
17527 COMP_HI_
LIM
+INF
High limit of compensation factor f
28
17528 COMP_LO_
LIM
-INF
Low limit of compensation factor f
29
17529 ARITH_
TYPE
1 to 10
0x01
Computation algorithm identification number.
Value
Selection Name
Description
1
Flow compensation,
linear
Flow compensation
(linear)
2
Flow compensation,
square root
Flow compensation
(square root)
3
Flow compensation,
approximate
Flow compensation
(approximate
expression)
4
BTU flow (*)
Quantity of heat
calculation
5
Traditional Multiply
Divide
Multiplication and
division
6
Average
Average calculation
7
Traditional summer
Summation
8
Fourth order
Polynomial, Type 1
4th-order (auxiliary
input) polynomial
computation
9
HTG level
compensation (*)
HTG level
compensation
10
Fourth order
Polynomial ,Type 2
4th-order (main
input) polynomial
computation
* BTU stand for British thermal value
HTG stands for hydrostatic tank gauging
30
17530 BAL_TIME More than
0
0
Time taken to return to the set value
31
17531 BIAS
0
Bias value used to calculate the output
32
17532 GAIN
1
Gain value used to calculate the output
33
17533 OUT_HI_
LIM
+INF
Maximum output value
34
17534 OUT_LO_
LIM
-INF
Minimum output value
35
17535 UPDATE_
EVT
Indicate event information if an update (setting change)
occurs.
36
17536 BLOCK_
ALM
Indicates alarm information if a block alarm occurs.
