Page 114

A-3
IM 21B04C01-01E
Relative
Index Index
Parameter Name
Default
(factory setting)
Write
Description
39
1039 WRITE_PRI
0
.
Defines the priority level of WRITE_ALM as well
as allows for notification to be disabled and makes
acknowledgment unnecessary for WRITE_ALM
40
1040 WRITE_ALM
—
—
Alarm generated when WRITE_LOCK is set to
unlocked
41
1041 ITK_VER
—
Version number of the inter-operability test kit
42
1042 SOFT_REV
—
—
Revision number of software
43
1043 SOFT_DSC
—
—
Revision number of software for development
purpose.
44
1044 SIM_ENABLE_MSG Null
—
Used to determine whether to enable the
simulation function to run. To enable, set
“REMOTE LOOP TEST SWITCH”.
45
1045 DEVICE_STATUS_1 0
—
Shows device statuses - mainly link object setting
statuses.
46
1046 DEVICE_STATUS_2 0
—
Shows device statuses - mainly individual for each
block status.
47
1047 DEVICE_STATUS_3 0
—
Shows device statuses - mainly the contents of
XD_ERROR in each block.
48
1048 DEVICE_STATUS_4 0
—
Not used in the YVP110.
49
1049 DEVICE_STATUS_5 0
—
Not used in the YVP110.
50
1050 DEVICE_STATUS_6 0
—
Not used in the YVP110.
51
1051 DEVICE_STATUS_7 0
—
Not used in the YVP110.
52
1052 DEVICE_STATUS_8 0
—
Not used in the YVP110.
*1: FF-891 “Foundation
TM
Specification Function Block Application Process Part 2”
A1.2 Parameters of Transducer Block
Parameters marked with (*1) are automatically set and changed by autotuning. Parameters marked with (*2)
are automatically set and changed by Travel calibration.
Relative
Index Index
Parameter Name
Default
(factory setting)
Write
Description [Setting range]
0
2000 Block Header
Block tag
= O/S
Information about this block, including the block
tag, DD revision, execution time
1
2001 ST_REV
0
—
Incremented when a change is made to the
parameter settings for the transducer block to
indicate the revision level of the settings, and
used to see whether or not there is a change in
parameter settings.
2
2002 TAG_DESC
Spaces
Universal parameter storing the description of the
tag
3
2003 STRATEGY
1
Universal parameter used by an upper-level
system to classify the function blocks.
4
2004 ALERT_KEY
1
Universal parameter used as a key to identify
the point from which an alert is issued; normally
used by an upper-level system to select alerts
to provide to a particular operator who covers a
specific area of the plant.
5
2005 MODE_BLK
O/S
Universal parameter that indicates the block
operation conditions and is composed of the
actual mode, target mode, permitted modes, and
normal mode.
6
2006 BLOCK_ERR
—
—
Indicates the error statuses related to the block
itself.
7
2007 UPDATE_EVT
—
—
Shows the contents of an update event upon
occurrence.
8
2008 BLOCK_ALM
—
—
Universal parameter indicating the hardware and
software error statuses related to the block itself
